Battery data | |
Cell materials | LiFePO4 |
Nominal capacity | 100Ah |
Rated voltage | 51.2V |
Energy | 5120Wh |
Communication method | CAN |
Charge cut-off voltage | 58.4V |
Discharge cut-off voltage | 41.6V |
Maximum charge current | 100A |
Maximum discharge current | 100A |
Cycle life | ≥3,000 Times |
Internal impedance | ≤100mΩ |
Ambient temperature | -10℃~50℃ |
AC input | |
Main topology | L+N+PE |
Rated voltage | 208/220/Default 230/240VAC |
AC output | |
Output voltage waveform | Pure sine wave |
Output voltage | 208/220/Default 230/240VAC |
Nominal output power | 5.5KW |
General parameters | |
IP protection level | IP21 |
Operating temperature range | -20℃~+60℃ |
Ambient humidity | 5-95%(No condensation ） |
Quality guarantee | 5 Years for battery cells and 2 years for inverter boards |
Operating altitude | <2000m> |
Cooling | Intelligent air cooling |
Demension | 610*937*161.2mm |
Weight | 75kg |
Noise | <60db> |
