Battery data | |
Cell materials | LiFePO4 |
Nominal capacity | 300Ah |
Rated voltage | 51.2V |
Energy | 15.36KWh |
Communication method | CAN、RS485、RS232 |
Charge cut-off voltage | 58.4V |
Discharge cut-off voltage | 44V |
Maximum charge current | 100A |
Maximum discharge current | 100A |
Cycle life | ≥6,000 Times |
Internal impedance | ≤20mΩ |
Ambient temperature | -20℃~55℃ |
AC input | |
Main topology | L+N+PE |
Rated voltage | 230VAC |
AC output | |
Output voltage waveform | Pure sine wave |
Output voltage | 230VAC |
Nominal output power | 5KW |
General parameters | |
IP protection level | IP65 |
Operating temperature range | -20℃~55℃ |
Ambient humidity | 5-95%(No condensation ） |
Quality guarantee | 5 Years for battery cells and 2 years for inverter boards |
Operating altitude | <2000m> |
Cooling | Intelligent air cooling |
Demension | 680×300×1630(mm) |
Weight | 140kg |
Noise | <50db> |
