Modle | N-BES-500kW/1000kWh | N-BES-1000kw/2500kwh | ||
DC data | ||||
DC data | LFP | |||
Cell cycle life | 8000 Cycles | 10000 Cycles | 8000 Cycles | 10000 Cycles |
Battery specifications | 3.2V/280Ah | 3.2V/314Ah | 3.2V/280Ah | 3.2V/314Ah |
Number of batteries in series and parallel | 1P224S | |||
Number of battery clusters | 5 | 10 | ||
Rated power | 1003.52kWh | 1125.37kWh | 2007.04kWh | 2250.75kWh |
Rated voltage | 716.8V | |||
Voltage range | 627.2V~817.6V | |||
Exchange data | ||||
Rated AC power | 500kW | 1000kW | ||
Rated voltage | 400V | |||
AC rated current | 722A | 1444A | ||
Output THDi | ＜3% | |||
Communication PF | 0.1~1 lead or lag (configurable) | |||
AC output | Three phase four wire+PE | |||
Common data | ||||
Dimensions | 6,058x2,438x2,591mm | 1,219x2,438x2,591mm | ||
Weight | ≥20t | ≥40t | ||
IP protection level | IP54 | |||
Range of working temperature | -20~40℃ | |||
Relative humidity | 0~95% | |||
Maximum working altitude | ＞2000m | |||
Cooling method | Forced air cooling | |||
