PowerPorter 5.0

Compact Size / High Efficiency / Easy Installation / High Energy Density

Powerporter is a lithium-ion battery that can store electrical energy and outputs DC current. Powerporter only maintains electrical connection with the inverter. The electrical energy generated by the PV is converted by the inverter Dc to DC and stored in the connected Powerporter. When Powerporter is needed, Powerporter’s electrical energy is converted by the inverter DC to AC and transmitted to the home grid to provide power for household appliances.

(Note: The actual Residential ESS may also include electrical equipment such as distribution boxes and metering meters)

Play Video

Datasheet

User Manual

Join Xinrex's Elite Partner Network.

FEATURES

LFP Cells. Cobalt Free

Can Be Wall Or Floor Mounted

The Battery Is More Integrated And Lighter

Metal Case And Tiny Size

Fast Charge And Discharge. No Memory Effect

Match With Mainstream Inverter Brands

SPECIFICATION

Battery Data
Rated Voltage	51.2V
Rated Energy	5.1kWh
Cell Capacity	100Ah
Discharging Voltage	45~54V
Charging Voltage	51.5V~54V
Operating Temperature	0℃ ~ 45℃ (Charge) -20℃ ~ 45℃ (Discharge)
Cont. Charging Current	100A
Peak Charging Current	100A
Cont. Discharging Current	100A
Peak .Discharging Current	100A
Rated. Discharging Power	5000W
Max.Discharging DC Power	5000W More than 2 units

General Data
IP Grade	IP31
Scalability	Up To 4 Units
DOD	90%
Installation	Wall or Floor mount
Dimension	745×460×165mm
Weight	51kg
Authentication	UN CE
Compatible Inverter	GoodWe/Deye/Megarevo/Growatt/Lux Power/TBB/Victron/Srne/Must/Senergy/Voltronic/Aptai/Sofar/Sma,etc

UN38.3、IEC62619、CE

* When the temperature is below 0 ℃ or above 45℃, the performance will be limited.
