FEATURES

LFP Cells. Cobalt Free

LFP Cells. Cobalt Free

Can Be Wall Or Floor Mounted

Can Be Wall Or Floor Mounted

The Battery Is More Integrated And Lighter

The Battery Is More Integrated And Lighter

Metal Case And Tiny Size

Metal Case And Tiny Size

Fast Charge And Discharge. No Memory Effect

Fast Charge And Discharge. No Memory Effect

Match With Mainstream Inverter Brands

Match With Mainstream Inverter Brands

SPECIFICATION

Battery Data

Rated Voltage

51.2V

Rated Energy

10.2kWh

Cell Capacity

202Ah

Discharging Voltage

45~54V

Charging Voltage

51.5V~54V

Operating Temperature

0℃ ~ 45℃ (Charge)

-20℃ ~ 45℃ (Discharge)

Cont. Charging Current

100A

Peak Charging Current

125A

Cont. Discharging Current

100A

Peak .Discharging Current

125A

Rated. Discharging  Power

5000W

Max.Discharging DC Power

5000W More than 2 units


General Data

IP Grade

IP31

Scalability

Up To 4 Units

DOD

90%

Installation

Wall or Floor mount

Dimension

830×460×200mm

Weight

93kg

Authentication

UN CE

Compatible Inverter

GoodWe/Deye/Megarevo/Growatt/Lux Power/TBB/Victron/Srne/Must/Senergy/Voltronic/Aptai/Sofar/Sma,etc
